Single-cylinder engine

A working engine: block, crankshaft, connecting rod with bolts and nuts, piston and wrist pin, all joined. Press play to turn the crank; explode it or read its parts list.

Single-cylinder engine: the part as it comes

How to make yours

  1. Turn it around in the 3D view to see how the parts fit together.
  2. Press Make it mine: a copy of your own opens in Assembly, with every part and joint.
  3. Press play on its Motion step to watch it move.
  4. In Assembly, pull it apart with Explode, read its parts list, or export it as STEP.

Also called

single cylinder engine model, engine assembly, crankshaft and piston, connecting rod model, printable engine, engine cad model.
