Gridfinity lighter bin generator
A Gridfinity bin with a pocket for each lighter, standing up: pocket lighters, torch lighters. Set its size and how many.
How to make yours
- Set the lighter's thickness and width; each slot is a little bigger so it drops in.
- Set how many lighters along and how many rows; the bin grows one 42 mm square at a time to hold them.
- Set how deep each slot is, and tick on magnet holes if your baseplate has magnets.
- Download it as STL, 3MF or STEP, and print it.
What each slider does
- Lighter thickness 8 to 25 mm
- How thick the lighter is.
- Lighter width 15 to 40 mm
- How wide the lighter is.
- Lighters along 1 to 10
- How many lighters sit side by side in a row.
- Rows 1 to 4
- How many rows of pockets there are, front to back.
- Pocket depth 10 to 60 mm
- How deep each lighter sits; the bin's height follows in 7 mm Gridfinity units.
- Magnet holes on or off
- Holes under each foot for magnets that hold the bin to a magnetic baseplate.
Also called
gridfinity lighter holder, lighter holder, lighter organizer, lighter stand, drawer organizer, gridfinity bin.
Gridfinity by Zack Freedman (MIT)
