Gridfinity filament swatch bin generator
A Gridfinity bin with a slot for each filament swatch, standing up so the colours show side by side. Set the swatch size and how many.
How to make yours
- Set the swatch's thickness and width; each slot is a little bigger so it drops in.
- Set how many swatches along and how many rows; the bin grows one 42 mm square at a time to hold them.
- Set how deep each slot is, and tick on magnet holes if your baseplate has magnets.
- Download it as STL, 3MF or STEP, and print it.
What each slider does
- Swatch thickness 1 to 5 mm
- How thick the swatch is.
- Swatch width 20 to 80 mm
- How wide the swatch is, side to side.
- Swatches along 1 to 20
- How many swatches sit side by side in a row.
- Rows 1 to 3
- How many rows of pockets there are, front to back.
- Pocket depth 8 to 40 mm
- How deep each swatch sits; the bin's height follows in 7 mm Gridfinity units.
- Magnet holes on or off
- Holes under each foot for magnets that hold the bin to a magnetic baseplate.
Also called
gridfinity swatch holder, filament swatch holder, filament sample storage, swatch organizer, 3d printing swatch, color swatch holder.
Gridfinity by Zack Freedman (MIT)
