Gridfinity dice bin generator
A Gridfinity bin with a square pocket for each die, in rows: six-sided dice or a whole tabletop set. Set the die size and how many.
How to make yours
- Set the die size, edge to edge; each pocket is 0.8 mm bigger.
- Set how many dice along and how many rows; the bin grows one 42 mm square at a time to hold them.
- Set how deep each slot is, and tick on magnet holes if your baseplate has magnets.
- Download it as STL, 3MF or STEP, and print it.
What each slider does
- Die size 8 to 30 mm
- How big each die is, edge to edge; the pocket is 0.8 mm bigger.
- Dice along 1 to 10
- How many dice sit side by side in a row.
- Rows 1 to 6
- How many rows of pockets there are, front to back.
- Pocket depth 4 to 30 mm
- How deep each die sits; the bin's height follows in 7 mm Gridfinity units.
- Magnet holes on or off
- Holes under each foot for magnets that hold the bin to a magnetic baseplate.
Also called
gridfinity dice holder, dice holder, dice tray, dice storage, tabletop dice organizer, board game organizer.
Gridfinity by Zack Freedman (MIT)
